[리눅스] HP ssacli(Smart Storage Administrator) 다운로드 URL

728x90

HP ssacli(Smart Storage Administrator) 다운로드 URL

Repository Listing

https://downloads.linux.hpe.com/SDR/repo/mcp/centos



HPE Software Delivery Repository



downloads.linux.hpe.com



Smart Storage Administrator (ssacli) 다운로드

Array Configuration Utility(acucli) 다운로드

ssacli 설치

$ cat /etc/redhat-release
CentOS Linux release 8.2.2004 (Core)

$ wget https://downloads.linux.hpe.com/SDR/repo/mcp/centos/8/x86_64/current/ssacli-4.17-6.0.x86_64.rpm

$ dnf install -y ssacli-4.17-6.0.x86_64.rpm

$ ssacli ctrl all show config

Smart Array P420i in Slot 0 (Embedded)    (sn: 0014153319EAB10)

   Internal Drive Cage at Port 1I, Box 2, OK

   Internal Drive Cage at Port 2I, Box 0, OK

   Port Name: 1I

   Port Name: 2I

   Array A (SAS, Unused Space: 0  MB)

      logicaldrive 1 (1.64 TB, RAID 5, OK)

      physicaldrive 1I:2:1 (port 1I:box 2:bay 1, SAS HDD, 900 GB, OK)
      physicaldrive 1I:2:2 (port 1I:box 2:bay 2, SAS HDD, 900 GB, OK)
      physicaldrive 1I:2:3 (port 1I:box 2:bay 3, SAS HDD, 900 GB, OK)

   SEP (Vendor ID PMCSIERA, Model SRCv8x6G) 380  (WWID: 50111380319EAB1F)

CentOS 7에 ssacli tools 설치

다운로드 링크 : https://downloads.linux.hpe.com/SDR/repo/mcp/centos/7/x86_64/12.20/

- 설치 환경

$ cat /etc/redhat-release
CentOS Linux release 7.9.2009 (Core)


$ getconf LONG_BIT
64

- ssacli(ssacli-5.10-44.0.x86_64.rpm)패키지 다운로드

$ wget https://downloads.linux.hpe.com/SDR/repo/mcp/centos/7/x86_64/12.20/ssacli-5.10-44.0.x86_64.rpm

- ssacli 패키지 설치

$ yum install -y ssacli-5.10-44.0.x86_64.rpm

- ssacli 명령어

ssacli ctrl all show config

$ ssacli ctrl all show config

Smart HBA H240ar in Slot 0 (Embedded) (RAID Mode)  (sn: PTNLN1BRH9Z2BP)

   Internal Drive Cage at Port 1I, Box 3, OK

   Internal Drive Cage at Port 2I, Box 0, OK

   Port Name: 1I

   Port Name: 2I

   Array A (Solid State SATA, Unused Space: 0  MB)

      logicaldrive 1 (372.56 GB, RAID 5, OK)

      physicaldrive 1I:3:1 (port 1I:box 3:bay 1, SATA SSD, 200 GB, OK)
      physicaldrive 1I:3:2 (port 1I:box 3:bay 2, SATA SSD, 200 GB, OK)
      physicaldrive 1I:3:3 (port 1I:box 3:bay 3, SATA SSD, 200 GB, OK)

ssacli ctrl slot=0 pd all show

$ ssacli ctrl slot=0 pd all show

Smart Array P420i in Slot 0 (Embedded)

   Array A

      physicaldrive 1I:1:1 (port 1I:box 1:bay 1, SAS HDD, 300 GB, OK)
      physicaldrive 1I:1:2 (port 1I:box 1:bay 2, SAS HDD, 300 GB, OK)

ssacli ctrl slot=0 pd 1I:1:1 show detail

$ ssacli ctrl slot=0 pd 1I:1:1 show detail

Smart Array P420i in Slot 0 (Embedded)

   Array A

      physicaldrive 1I:1:1
         Port: 1I
         Box: 1
         Bay: 1
         Status: OK
         Drive Type: Data Drive
         Interface Type: SAS
         Size: 300 GB
         Drive exposed to OS: False
         Logical/Physical Block Size: 512/512
         Rotational Speed: 10000
         Firmware Revision: HPDC
         Serial Number: KFH4300R
         WWID: 5000CCA0543FD101
         Model: HP      EG0300FBVFL
         Current Temperature (C): 38
         Maximum Temperature (C): 43
         PHY Count: 2
         PHY Transfer Rate: 6.0Gbps, Unknown
         PHY Physical Link Rate: Unknown, Unknown
         PHY Maximum Link Rate: Unknown, Unknown
         Drive Authentication Status: OK
         Carrier Application Version: 11
         Carrier Bootloader Version: 6
         Sanitize Erase Supported: False
         Shingled Magnetic Recording Support: None

레이드 구성(raid 1)

ssacli ctrl all show config

$ ssacli ctrl all show config

ssacli ctrl slot=0 create type=ld drives=1I:1:3,1I:1:4 raid=1

$ ssacli ctrl slot=0 create type=ld drives=1I:1:3,1I:1:4 raid=1

Warning: Controller cache is disabled. Enabling logical drive cache will not take effect until this has been resolved.

ssacli ctrl all show config

$ ssacli ctrl all show config
