[리눅스] named(bind)에 geoip 기능 사용하기

named(bind)에 geoip 기능 사용하기

yum install gcc epel-release

yum install zlib-devel openssl-devel

yum install GeoIP GeoIP-devel

yum install bind bind-utils



[bind download site]

http://ftp.isc.org/isc/bind9/9.10.4-P6/

cd /usr/local/src/

wget http://ftp.isc.org/isc/bind9/9.10.4-P6/bind-9.10.4-P6.tar.gz

tar xfz bind-9.10.4-P6.tar.gz

cd bind-9.10.4-P6

./configure --prefix=/usr/local/bind-9.10.4-P6 --sysconfdir=/etc --localstatedir=/var --enable-threads --without-openssl --with-geoip=/usr/share/GeoIP

make && make install



cd /usr/local/bind-9.10.4-P6/sbin

./named -V | sed -r 's/ +/\n/g' | grep geoip

$ ./named -V | sed -r 's/ +/\n/g'|grep geoip
'--with-geoip=/usr/share/GeoIP'

ldd ./named | grep libGeoIP

$ ldd ./named | grep libGeoIP
        libGeoIP.so.1 => /usr/lib64/libGeoIP.so.1 (0x00007f3284d00000)

파일 복사

cp /usr/local/bind-9.10.4-P6/sbin/named /usr/sbin/named

cp /usr/local/bind-9.10.4-P6/sbin/named-checkconf /usr/sbin/named-checkconf

cp /usr/local/bind-9.10.4-P6/sbin/named-checkzone /usr/sbin/named-checkzone



vim /etc/named.conf

acl "country_KR" {
        geoip country KR;
        #geoip region CA;
        #geoip city "Redwood City";
        /* names, etc., must be quoted if they contain spaces */
};

options {
#       listen-on port 53 { 127.0.0.1; };
#       listen-on-v6 port 53 { ::1; };
        directory       "/var/named";
        dump-file       "/var/named/data/cache_dump.db";
        statistics-file "/var/named/data/named_stats.txt";
        memstatistics-file "/var/named/data/named_mem_stats.txt";
        allow-query     { any; };
        recursion yes;

        geoip-directory "/usr/share/GeoIP";

        dnssec-enable yes;
        dnssec-validation yes;

        /* Path to ISC DLV key */
        bindkeys-file "/etc/named.iscdlv.key";

        managed-keys-directory "/var/named/dynamic";
};

include "/etc/named.logging.conf";
#include "/etc/named.rfc1912.zones";
include "/etc/named.root.key";

view "ACL_KR" {
      match-clients { country_KR; };
      recursion yes;

             zone "." IN {
                                        type hint;
                                        file "named.ca";
                                        };

             zone "localhost" IN {
                                        type master;
                                        file "named.localhost";
                                        allow-update { none; };
                                        };


             zone "1.0.0.127.in-addr.arpa" IN {
                                        type master;
                                        file "named.loopback";
                                        allow-update { none; };
                                        };

             zone "example.com" IN {
                                        type master;
                                        file "example.com-KR.zone";
                                        allow-update { none; };
                                        };
};

view "OTHER" {
      match-clients { any; };
      recursion yes;

             zone "." IN {
                                        type hint;
                                        file "named.ca";
                                        };

             zone "localhost" IN {
                                        type master;
                                        file "named.localhost";
                                        allow-update { none; };
                                        };

             zone "1.0.0.127.in-addr.arpa" IN {
                                        type master;
                                        file "named.loopback";
                                        allow-update { none; };
                                        };

             zone "example.com" IN {
                                        type master;
                                        file "example.com-ETC.zone";
                                        allow-update { none; };
                                        };
};



vim /var/named/example.com-KR.zone

$TTL 60
@       IN SOA  @ rname.invalid. (
                                        0       ; serial
                                        1D      ; refresh
                                        1H      ; retry
                                        1W      ; expire
                                        3H )    ; minimum

                        IN      NS      ns1.example.com.

                        IN      A       1.1.1.1
www                     IN      A       1.1.1.1

ns1                     IN      A       192.168.56.101



vim /var/named/example.com-ETC.zone

$TTL 60
@       IN SOA  @ rname.invalid. (
                                        0       ; serial
                                        1D      ; refresh
                                        1H      ; retry
                                        1W      ; expire
                                        3H )    ; minimum

                        IN      NS      ns1.example.com.

                        IN      A       2.2.2.2
www                     IN      A       2.2.2.2

ns1                     IN      A       192.168.56.101
