[kubernetes] kubectl explain 명령

728x90

kubectl explain 명령

List the fields for supported resources.

사용법

Examples:
  # Get the documentation of the resource and its fields
  kubectl explain pods

  # Get the documentation of a specific field of a resource
  kubectl explain pods.spec.containers

Options:
      --api-version='': Get different explanations for particular API version (API group/version)
      --recursive=false: Print the fields of fields (Currently only 1 level deep)

Usage:
  kubectl explain RESOURCE [options]

Use "kubectl options" for a list of global command-line options (applies to all commands).



kubectl api-resources



kubectl explain pod
kubectl explain --api-version batch/v1beta1 cj
$ kubectl explain pod
KIND:     Pod
VERSION:  v1

DESCRIPTION:
     Pod is a collection of containers that can run on a host. This resource is
     created by clients and scheduled onto hosts.

FIELDS:
   apiVersion	<string>
     APIVersion defines the versioned schema of this representation of an
     object. Servers should convert recognized schemas to the latest internal
     value, and may reject unrecognized values. More info:
     https://git.k8s.io/community/contributors/devel/sig-architecture/api-conventions.md#resources

   kind	<string>
     Kind is a string value representing the REST resource this object
     represents. Servers may infer this from the endpoint the client submits
     requests to. Cannot be updated. In CamelCase. More info:
     https://git.k8s.io/community/contributors/devel/sig-architecture/api-conventions.md#types-kinds

   metadata	<Object>
     Standard object's metadata. More info:
     https://git.k8s.io/community/contributors/devel/sig-architecture/api-conventions.md#metadata

   spec	<Object>
     Specification of the desired behavior of the pod. More info:
     https://git.k8s.io/community/contributors/devel/sig-architecture/api-conventions.md#spec-and-status

   status	<Object>
     Most recently observed status of the pod. This data may not be up to date.
     Populated by the system. Read-only. More info:
     https://git.k8s.io/community/contributors/devel/sig-architecture/api-conventions.md#spec-and-status
kubectl explain pod.spec
kubectl explain pod.spec.containers
$ kubectl explain pod.spec.containers.ports
KIND:     Pod
VERSION:  v1

RESOURCE: ports <[]Object>

DESCRIPTION:
     List of ports to expose from the container. Exposing a port here gives the
     system additional information about the network connections a container
     uses, but is primarily informational. Not specifying a port here DOES NOT
     prevent that port from being exposed. Any port which is listening on the
     default "0.0.0.0" address inside a container will be accessible from the
     network. Cannot be updated.

     ContainerPort represents a network port in a single container.

FIELDS:
   containerPort	<integer> -required-
     Number of port to expose on the pod's IP address. This must be a valid port
     number, 0 < x < 65536.

   hostIP	<string>
     What host IP to bind the external port to.

   hostPort	<integer>
     Number of port to expose on the host. If specified, this must be a valid
     port number, 0 < x < 65536. If HostNetwork is specified, this must match
     ContainerPort. Most containers do not need this.

   name	<string>
     If specified, this must be an IANA_SVC_NAME and unique within the pod. Each
     named port in a pod must have a unique name. Name for the port that can be
     referred to by services.

   protocol	<string>
     Protocol for port. Must be UDP, TCP, or SCTP. Defaults to "TCP".



kubectl explain pod.spec.containers.ports
$ kubectl explain --api-version batch/v1beta1 cj
KIND:     CronJob
VERSION:  batch/v1beta1

DESCRIPTION:
     CronJob represents the configuration of a single cron job.

FIELDS:
   apiVersion	<string>
     APIVersion defines the versioned schema of this representation of an
     object. Servers should convert recognized schemas to the latest internal
     value, and may reject unrecognized values. More info:
     https://git.k8s.io/community/contributors/devel/sig-architecture/api-conventions.md#resources

   kind	<string>
     Kind is a string value representing the REST resource this object
     represents. Servers may infer this from the endpoint the client submits
     requests to. Cannot be updated. In CamelCase. More info:
     https://git.k8s.io/community/contributors/devel/sig-architecture/api-conventions.md#types-kinds

   metadata	<Object>
     Standard object's metadata. More info:
     https://git.k8s.io/community/contributors/devel/sig-architecture/api-conventions.md#metadata

   spec	<Object>
     Specification of the desired behavior of a cron job, including the
     schedule. More info:
     https://git.k8s.io/community/contributors/devel/sig-architecture/api-conventions.md#spec-and-status

   status	<Object>
     Current status of a cron job. More info:
     https://git.k8s.io/community/contributors/devel/sig-architecture/api-conventions.md#spec-and-status
